Application : Designed for suction and discharge use on various petroleum products with upto 50% aromatic content, whether in plant or on tankers. Is suitable for handling unleaded fuels and hydraulic oils in return lines and wet diesel exhaust.
Working pressure: 10 bar (150psi), safety factor 3:1. Vacuum I bar. Lining: Black NBR for 50% aromatics. Reinforcement: High strength textile yarn, high tensile carbon steel helix and copper anti-static wire. Cover: Black CR oil, ozone and weather resistant
| Dimensions MM |
Pressure Bar | Weight KG/M (Approximate) | Bend Radius MM (Approximate) | Coil Length Metre | |||
|---|---|---|---|---|---|---|---|
| Positive | Vacuum | ||||||
| id | od | Working | Burst | ||||
| 19 | 29 | 10 | 30 | 1 | 0.60 | 140 | 61 |
| 25 | 35 | 10 | 30 | 1 | 0.70 | 178 | 61 |
| 32 | 42 | 10 | 30 | 1 | 0.80 | 224 | 61 |
| 38 | 47 | 10 | 30 | 1 | 0.90 | 266 | 61 |
| 51 | 62 | 10 | 30 | 1 | 1.60 | 357 | 61 |
| 63 | 74 | 10 | 30 | 1 | 1.90 | 441 | 61 |
| 76 | 87 | 10 | 30 | 1 | 1.50 | 530 | 61 |
| 102 | 114 | 10 | 30 | 1 | 3.80 | 714 | 61 |
| 152 | 172 | 10 | 30 | 1 | 9.50 | 1064 | 30.5 |
